A full selection of highly efficient manual disc filters to clean any water source. Netafim disc filters collect debris along the depth of the discs, not just at the surface like screen filters. The disc helps filtration with calcium buildup.
Plastic rings stack together creating a cylindrical filter element. During filtration, the rings are compressed together effectively filtering the water and protecting the system from clogging. Works well as a stand-alone unit or combined to form modular filter batteries.
Applications
Features & Benefits
Disc Filter Technology
Grooves in the disc rings crisscross to form a network that traps debris between and on the outside of the discs.
How It Works
As dirty water is pumped into the filter, and pressure increases, the water compresses the disc rings together tightly. The water is then forced to flow through the grooves of the disc rings, where debris is trapped, releasing only clean water to the irrigation system.
Specifications
| Brand | Netafim |
|---|---|
| SKU | 00135-000020 |
| Weight (lb.) | 0.8100 |
| Prop 65 | false |
| Width (in.) | |
| Height (in.) | |
| Lead Time | 10-14 |
| Length (in.) | |
| Hazardous Material | false |
| UL Listed | No |
| ETL Listed | No |
| Irrigation Part Type | |
| Mesh | 120 Mesh |
What does Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) do in an irrigation system?
Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) removes debris from water and helps protect irrigation systems from clogging. The disc design collects debris along the depth of the discs, not just on the surface like a screen filter.
Can Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) be used alone or in a filter battery?
Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) works well as a stand-alone unit or combined to form modular filter batteries.
What water sources can Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) clean?
Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) is designed to clean any water source. The product description lists residential, commercial, municipal, and institutional applications.
What materials are used in Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120)?
Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) uses a reinforced polyamide body and cover, polypropylene disc rings, EPDM rubber O-rings, and stainless steel clamps.
Does Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) reduce cleaning needs?
Netafim Manual Disc Filter, 3/4 Inch, 120 Mesh (DF075-120) has extra large filtration capacity, which requires less cleaning.
