A full selection of highly efficient manual disc filters to clean any water source. Netafim disc filters collect debris along the depth of the discs, not just at the surface like screen filters. The disc helps filtration with calcium buildup.
Plastic rings stack together creating a cylindrical filter element. During filtration, the rings are compressed together effectively filtering the water and protecting the system from clogging. Works well as a stand-alone unit or combined to form modular filter batteries.
Applications
Features & Benefits
Disc Filter Technology
Grooves in the disc rings crisscross to form a network that traps debris between and on the outside of the discs.
How It Works
As dirty water is pumped into the filter, and pressure increases, the water compresses the disc rings together tightly. The water is then forced to flow through the grooves of the disc rings, where debris is trapped, releasing only clean water to the irrigation system.
Specifications
What does the Netafim Manual Disc Filter do in an irrigation system?
The Netafim Manual Disc Filter, 1 Inch, 120 Mesh (DF100-120) cleans water by trapping debris deep within stacked disc grooves, not just at the surface like a screen filter. The disc design also helps with calcium buildup and protects the irrigation system from clogging.
Can the Netafim Manual Disc Filter be used by itself or in a larger filter bank?
The Netafim Manual Disc Filter, 1 Inch, 120 Mesh (DF100-120) works as a stand-alone unit or combined to form modular filter batteries. That flexibility suits a range of irrigation setups.
What flow and pressure range fit the 1-inch Netafim Manual Disc Filter?
The Netafim Manual Disc Filter, 1 Inch, 120 Mesh (DF100-120) is rated for 5 to 26 GPM and up to 140 psi. That range fits the 1-inch model listed in the product name.
Where can the Netafim Manual Disc Filter be used?
The Netafim Manual Disc Filter, 1 Inch, 120 Mesh (DF100-120) is suited for residential, commercial, municipal, and institutional applications. The filter is described as useful for cleaning many types of water sources.
What helps the Netafim Manual Disc Filter handle dirt buildup and long-term use?
The Netafim Manual Disc Filter, 1 Inch, 120 Mesh (DF100-120) uses 100% thermoplastic discs that are corrosion resistant, and the disc screens help prevent elements from collapsing. The filter also has extra large filtration capacity, which means less cleaning.
