Iluminar Product Documents
Iluminar iLogic MS Plus 700 User Manual Iluminar iLogic MS Plus 700 Spec SheetNew Generation High Intensity LED Lighting
The iLogic™ MS Plus 700W is our new powerhouse full life-cycle / flowering LED lighting fixture featuring multi-channel control.
Now growers can precisely and independently specify the timing and intensity of far-red, UV-A, and full spectrum light output during the light-cycle. This fine-tuning functionality is ideal for cultivators looking to reduce transition time between vegetative growth and flowering as well as boosting the production of secondary metabolites.
Energy Efficiency
Powered by highly-reliable Sosen LED Drivers and delivering a Power Factor exceeding 0.9, the iLogic™ MS Plus 700W optimizes energy usage, reducing operational costs without compromising performance.
Versatile Control
Compatible with iLuminar’s external PAD controller or smartphone app, growers can precisely control light intensity and customize spectra for specific cultivars.
Daisy-Chain Capability
Daisy-chain up to 256 fixtures, helping to simplify installation and management for larger setups.
High PPF Output
We've broken the 2000 barrier using just 700 watts of power! Boasting an incredible Photosynthetic Photon Flux (PPF) output of 2030 µmol/s combined with an outstanding efficacy of 2.9 µmol/J at full power, this fixture delivers the most intense illumination to drive full genetic expression, even in the most light-hungry cultivars.
Advanced, Tunable Spectrum LED for Indoor Floriculture
Harnessing the very latest LED technology, the iLogic™ MS Plus 700W combines 2520 Samsung LM281B+ Pro full spectrum diodes, 192 Honglitronic SMD3535 660nm diodes, 144 SMD3030 385nm UV diodes, and 144 SMD2835 730nm far-red diodes.
The timing and intensity of far-red, UV, and full spectrum diodes can be fully controlled throughout the light-cycle.
Full Spectrum 100% ON
Full Spectrum 100% ON + UV 100% ON
Full Spectrum 100% ON+ IR 100% ON
Full Spectrum 100% ON + UV 100% ON + IR 100% ON
UV 100% ON
IR 100% ON
Optional Upgrade: Iluminar Touch+ Grow Light Controller
The ILUMINAR Touch+ Controller will now allow you to control up to 60 lights per zone or room, with two channels you can control up to a total of 120 lights. This will take even your beginner garden to the commercial level, all of these features packed into the ILUMINAR Touch+ Controller.
The main difference between the Touch+ and the older Touch is greater dimming control. The old Touch controller could only control LEDs down to 50% dimming. The new Touch+ Controller can control dimming on LEDs all the way down to 20%
- LED + CMH + HPS All From One Controller
- Up to 120 Units, 60 fixtures per zone
- Control 2 Independent Rooms
- Auto Temperature Shut-Down
- Sunrise / Sunset Effects
- Battery Backup to Save Data
- Dual Temperature Zone input for High Heat Dimming
- Dual Temperature Probe Inputs
- Touch Screen Technology
- RJ9 to RJ14 cable included
Specifications for the Iluminar MS Plus 700
| Input Power | 120V to 277V |
|---|---|
| Power Consumption | 700W ± 5% |
| PPF | 448-480 µmol/s |
| ePAR | 2.9 µmol/J |
| ePAR - PPF | 2030 µmol/s |
| Power Factor | >0.9 |
| THD | <10% |
| Dimming | 0-100% dimming via RS485 |
| Frequency | 50/60 Hz |
|---|---|
| BTU | 2300 |
| LED Lifespan (90% of Life) | 50,000+ Hours |
| Ambient Temp / Working | 0° - 35°C / 32° - 95°F |
| Light Distribution | 120° |
| Waterproof Rating | IP65 |
| Color Temperature | 3600K |
| Color Rendering Index | 85 |
| Brand | Iluminar |
|---|---|
| SKU | IL-L700MS-120 |
| Weight (lb.) | 0.0000 |
| Prop 65 | false |
| Warranty | 5 Year |
| Lead Time | This Product Ships in 2-3 Days |
| Hazardous Material | false |
| Lighting Type | LED |
| LED Light Spectrum | Full Spectrum, Infrared, UV Spectrum |
| LED Fixture Type | Multi-Bar |
| LED Features | Dimmable *with Controller, Adjustable Spectrum |
| Est. Electricity Cost /mo | $30.24 |
| Exact Watts | 700 Watts |
| LED Diode Type | Samsung LM281B |
| LED Driver Type | Sosen LED Drivers |
| PAR Efficiency | Up to 2.9 µmol/J |
| Total PPF Output | 2030 µmol/ |
| Power Factor | >0.9 |
| Daisy Chain | Yes |
| Voltage | 120 Volts |
| Amps | 5.84 Amps @ 120 Volts |
| Frequency | 50/60 Hz |
| Power Cord(s) Included | Yes - 120 Volts |
| Power Cord Length | 6 ft. 10 in. |
| Coverage Area | Veg: 5' x 5'; Flower: 4' x 4' |
| Grow Light Certifications | IP65 Rated |
| ETL Listed | No |
| UL Listed | No |
What makes the Iluminar iLogic Plus 700W different from other LED fixtures?
The iLogic Plus is Iluminar's flagship fixture line — highest efficacy, best build quality in their catalog. Its key advantage is zero downtime: both the LED bars and the driver are field-replaceable. If a bar fails, replacing it takes removing 2 screws and swapping the bar back in, rather than shipping the entire fixture out for repair for weeks.
What control protocol does the iLogic Plus use?
The iLogic Plus runs on RS485 rather than the standard 0-10V protocol most fixtures use. A 0-10V channel typically supports around 60 fixtures per channel; RS485 supports 200-2000 fixtures depending on adapter configuration, making it significantly more scalable for large commercial facilities. It's certified to work with Argus, Priva, and Growlink control systems.
Do I need a special controller to run the iLogic Plus?
No. Growlink and other certified RS485 systems will work with the fixture directly. An adapter is also available to step the connection down to a standard 0-10V/foam cord setup if needed, though this adds an additional connection point.
Is the iLogic Plus multi-spectrum (independent UV and far red channels)?
Yes. The MS (multi-spectrum) version allows independent control of UV and far red channels in addition to the full spectrum array, letting growers fine-tune spectral output by growth stage.
If a bar or driver fails, what should I do?
Don't disconnect the failed bar and wait for a replacement — leaving a bar connected (even if malfunctioning) maintains the correct wattage draw the ballast expects, preventing damage to the driver. Commercial orders ship with extra bars and drivers on hand specifically so facilities can swap immediately without downtime.
What is the warranty on this fixture?
5 years on the LED fixture, consistent with Iluminar's LED warranty across the line.
