FloraFlex Product Documents
This inline fan system offers exceptional build quality in a value-packed design. It is ideal for quietly cooling grow tents, rooms, and closets, while also providing ventilation for various air circulation and exhaust needs. Featuring an inline mixed-flow design, the duct fan ensures consistent airflow, even in high static pressure conditions. The motor box, which houses the fan's impeller and blades, can be easily detached from the mounted frame for convenient cleaning and maintenance. The complete kit includes the inline fan unit, a speed controller, an installation manual, and all necessary mounting hardware.
FloraFlex Inline Fan with Speed Controller Specs
| Size | 4" | 6" | 8" | 10" | 12" |
|---|---|---|---|---|---|
| Voltage | 120 Volt | ||||
| Frequency | 60 Hz | ||||
| Power | 101 Watts | 174 Watts | 215 Watts | 239 Watts | 299 Watts |
| Current | 0.86 Amps | 1.45 Amps | 1.83 Amps | 2.00 Amps | 2.50 Amps |
| Speed | 2850 RPM | 2780 RPM | 3000 RPM | 2750 RPM | 2750 RPM |
| Air Flow | 189 CFM | 460 CFM | 720 CFM | 810 CFM | 1100 CFM |
| Noise | 48 DB | 60 DB | 54 DB | 56 DB | 62 DB |
| Pressure | 508 Pa | 673 Pa | 813 Pa | 864 Pa | 1016 Pa |
| Cord Length | 6 Ft | ||||
| EL Listed | Yes | ||||
The high-airflow duct filter is designed to remove odors and chemicals using activated carbon, making it ideal for applications such as hydroponics, grow rooms, kitchens, smoking areas, and other ventilation systems. It features a premium-grade Australian Virgin charcoal bed for effective filtration. The filter can be used with an inline duct fan in both intake and exhaust configurations. Built with heavy-duty construction, it includes aluminum flanges and dual-sided galvanized steel mesh, with reversible flanges to extend the filter's lifespan. The filter also comes with two machine-washable pre-filter cloths to prevent carbon residue and two hanging straps for easy installation.
- Designed to eliminate odors in grow rooms and tents.
- Features premium-grade Australian charcoal with higher absorption and longer life rating.
- Contains heavy-duty aluminum flanges, galvanized steel meshing, pre-assembled hanging bracket, and one clothed washable pre-filter.
- Enables maximum airflow passthrough for both intake and exhaust configurations.
- Carbon: Australian RC412 at 1200+ IAV
- Thickness: 38mm
This ducting is engineered for a wide range of ventilation, air circulation, and heating/cooling transfer applications. It boasts a four-layer construction, offering superior durability and leak resistance compared to single-layer alternatives. The inner layer is crafted from heavy-duty dual aluminum foil, which is flame and fire resistant. The outer layer features dual PVC thermoplastic, providing protection against cuts, tears, and leakage. An internal steel-wire spiral holds the duct together, ensuring flexibility for easy installation in tight spaces. The ducting can be cut to the desired length for different applications and comes with two stainless steel duct clamps.
- Designed for heating, cooling, ventilation, and exhaust applications
- Heavy-duty four-layer protection for enhanced durability and resistance to leaks, tears, and cuts
- Flexible steel-wire spiral structure for easy installation, even in hard-to-reach places
- Constructed of high-quality aluminum for optimal performance and longevity
| Brand | FloraFlex |
|---|---|
| SKU | FF-ODOR |
| Hazardous Material | false |
