The GCS-1 is an advanced, modular control system crafted to oversee irrigation, climate regulation, CO2 monitoring, lighting, and sophisticated sensor integration in greenhouses.
The GCS-1 controller offers an all-in-one solution for tracking and managing various elements of greenhouse activities. It connects with multiple devices and sensors to guarantee precise environmental control, fostering the best conditions for plant growth.
The GCS-1 includes a cutting-edge 4-in-1 sensor suite (MBS-GH) for accurate real-time tracking of temperature, humidity, and light intensity. For outside conditions, the controller can assess outdoor temperature and wind speed through the Weather Station Sensor (MBS-WS) while managing curtains and glass with the Single/Three Phase Curtain Motor Controller(AMC-1) & 24V DC Greenhouse Roll Up Motor Controller (DMC-1), thereby improving environmental monitoring and control by factoring in external temperature and weather conditions.
What's Included
- 1x Greenhouse Controller
- 1x Temp/Humid/CO2/Day&Night 4-in-1 Sensor (MBS-GH)
- 1x RJ12 Cable Set for Light Connection
- 1x 12V Power Adapter
- 1x RJ12 T-Splitter
Features & Benefits
- All-in-one Greenhouse Control System
- (Grow Lights / Climate / Irrigation / Curtain Motor / Ventilation)
- Modular Design & Fully Customizable
- Entry cost-friendly & incredible expansion potential
- Control up to 96 scheduled Irrigation outputs (24V or 110V)
- Climate/Irrigation/Crops Historical Data Logging
- Compatible with the free TrolMaster App
Specifications
- LCD Resolution: 256x160
- Input Voltage: 100-240VAC, 50/60Hz
- Output Current: 3A
- Temperature Range: 32~122℉ (0~50℃)
- Operating Humidity: 5~95% RH
Sensor Capacity:
- MBS-GH (Temp/Humid/Light) max 1pc per set
- MBS-WS (Weather Station) max 1pc per set
- MBS-PAR (PPFD) max 1pc per set
- MBS-SD (Smoke Detector) max 1pc per set
- AMP-3 (pH / EC / Temp) max 1pc per set
- DFM-1/2/3 (Digital Flow Meter) max 1pc per set
- WCS-1/2/3 (Water Content / EC / Temp) max 8pcs per set
- WD-1 (Water Detector) max 2pcs per set
Device Capacity:
- Temperature Device Stations max 4pcs per set
- Humidity Device Stations max 4pcs per set
- CO2 Device Stations: max 2pcs per set
- Program(Timer) Device Stations: max 2pcs per set
Irrigation Capacity(up to 96 outputs):
- Control Board & Device Station max 8pcs per set
- 24VDC Control Board (OA6-24): 6 outputs per device
- 24VDC Control Board (OAT-24): 12 outputs per device
- 110VAC Control Board (OA6-110): 6 outputs per device
- 100-240VAC Program Device Station(DSP-1/2): 1 output per device
- Dry Contact Station(DSD-1/2): 1 output per device
Motor Controller Capacity:
- AC & DC Motor Controller max 4pcs per set
EC Fan Control Capacity:
- EC Fan Control Adaptor(EFC-1) max 4pcs per set
Grow Light Control Capacity:
- 2 Lighting Channel(Line 1 & 2) max 256 fixtures per channel
- (numbers depending on the brand or grow light)
What greenhouse tasks can TrolMaster GCS-1 manage?
TrolMaster GCS-1 manages irrigation, climate regulation, CO2 monitoring, grow lighting, ventilation, curtain motors, and sensor integration in greenhouses.
How does TrolMaster GCS-1 monitor greenhouse and outdoor conditions?
TrolMaster GCS-1 includes an MBS-GH 4-in-1 sensor suite for real-time temperature, humidity, and light-intensity tracking. TrolMaster GCS-1 can also assess outdoor temperature and wind speed through an MBS-WS Weather Station Sensor.
What greenhouse equipment can TrolMaster GCS-1 connect with?
TrolMaster GCS-1 connects with greenhouse sensors, irrigation equipment, grow lights, climate devices, ventilation equipment, and curtain motor controllers, including AMC-1 and DMC-1 controllers.
How many irrigation outputs can TrolMaster GCS-1 control?
TrolMaster GCS-1 controls up to 96 scheduled irrigation outputs using 24V or 110V equipment.
What comes with TrolMaster GCS-1?
TrolMaster GCS-1 includes one greenhouse controller, one MBS-GH temperature, humidity, CO2, and day/night 4-in-1 sensor, one RJ12 cable set for light connection, one 12V power adapter, and one RJ12 T-splitter.
Can TrolMaster GCS-1 work with a mobile control app?
TrolMaster GCS-1 is compatible with the free TrolMaster App for greenhouse system management.
