The PHOTONTEK 50W FAR-RED LED BAR is a supplemental adding to your crop that has been specifically created to extend the X / XT series [400-700] nm Full-Spectrum range to [400-750] nm. The PHOTONTEK 50W FAR-RED LED BAR was designed to fit directly into the X / XT fixtures and when FAR-RED photons are mixed with the produced Full-Spectrum from the X / XT range, a 10-20% ratio is secured.
Designed to fit directly on the popular PHOTONTEK X / XT LED fixtures frames, the integration of the very valuable FAR-RED photons [701-750] nm harnesses the principles of the EMERSON Enhancement effect, allowing growers to promote steam elongation and leaf expansion during the vegetative and the early days of flowering stages enabling to fill in the grow area. Also, taking advantage of their high efficacy, they can be used at the end of the life cycle to improve the overall photosynthetic efficiency.
With its peak at 730 nm and an output of 13 µ¼mol/s [600-700] nm and 148 µ¼mol/s [701-750] nm, the PHOTONTEK 50W FAR-RED is a supplemental LED bar tool, to help growers enhance PSII photochemical efficiency and photosynthetic rate when added to the provided Full-Spectrum by the X / XT range.
This unit has an independent power source and can also be connected in series with daisy-chain link cables. To ensure unit performance, this LED bar has a single input and output socket for the Power Cable or Daisy Chain link Cable, depending on the use of that bar. For this reason, the Power 120V/240V (13 ft) and Daisy Chain (5 ft) cables are sold separately.
Recommended Coverage
The PHOTONTEK 50W FAR-RED LED BAR was designed to fit directly into the X / XT fixtures and when FAR-RED photons are mixed with the produced Full-Spectrum from the X / XT range, a 10-20% ratio is secured.
Integrate a minimum of 2 units of PHOTONTEK 50W FAR-RED LED BAR, with:
- X 465W PRO - 4 x 4 ft (1.2 x 1.2 m) footprint
- X 600W PRO - 4.5 x 4.5 ft (1.4 x 1.4 m) footprint
- XT 1000W CO2 - 5 x 5 ft (1.5 x 1.5 m) footprint w/ CO2 Supplement
Integrate a minimum of 3 units of PHOTONTEK 50W FAR-RED LED BAR, with:
- X 1000W PRO - 6.5 x 5 ft (2 x 1.5 m) footprint
Recommended Far-Red Application
Always mix the supplemental FAR-RED radiation with the previously mentioned PHOTONTEK X / XT Full-Spectrum LED Range. For a good FAR-RED radiation spread, ensure to install the recommended minimum units, and follow the distance to canopy referred on the Grow Light Strategies table.
FAR-RED can also damage plants. If you notice plant damage, we recommend increasing the distance between fixture and canopy or decrease the FAR-RED radiation delivered by reducing the photoperiodic time. There is no specific defined photoperiodic time as it will depend on the grower plant morphology preferences.
Photontek VF 120W LED Grow Light Features
- Promotes stem elongation and leaf expansion
- Enhance density of your grow area
- Improve the overall photosynthetic efficiency
- Attachable to all PHOTONTEK X / XT Full-Spectrum LED range
- Top efficacy FAR-RED diodes
- Plug and Play
- Internal LED Driver
- Daisy chain connectivity (up to 18 pcs.)
- Passive Cooling
- IP65
What's in the box?
- 1 x 50W FAR-RED LED BAR
- 2 x Stainless Steel Hook
Photontek 50 Watt Far-Red LED Bar Specs
-
PPF [400-750] nm: 155 µ¼mol/s
-
EFFICACY [400-750] nm: 3.1 µ¼mol/J
-
INPUT VOLTAGE: 120-277 V AC, 50-60 Hz
-
DRIVER: 50 W, 120-277 V AC, 50-60 Hz Integrated
-
INPUT POWER: 50 W (+/- 5%)
-
WATERPROOF/DUSTPROOF: IP65
-
LIFE SPAN: L90 > 45000 Hrs
-
LIGHT DISTRIBUTION: 140°
-
LIGHT SOURCE: FAR-RED LED DIODES
-
DIMENSIONS: 39.4" x 1.9" x 1.7" (1000 x 48 x 42 mm)
-
WEIGHT: 2.7 Lbs (1.2 kg)
-
THERMAL MANAGEMENT: Passive Heat Sink
-
POWER FACTOR: > 0.90
-
MAX AMBIENT TEMPERATURE: 104 °F (40 °C)
-
WORKING TEMPERATURE: 14 °F - 104 °F ( -10 °C - 40 °C)
-
WORKING HUMIDITY: 20% - 80% Non-Condensing
-
DIMMABLE: No
-
DAISY-CHAIN CAPABILITY: Yes (Max. 18 Pcs.)
