Netafim Product Documents
Netafim 80 Series Valves Specification SheetNetafim Series 80 Nylon Control 2-Way Valve
Lower Friction = Improved Performance
With lower friction loss providing improved performance, Netafim Series 80 Nylon Control Valves are specifically designed for greenhouse applications. Offered with a nylon body (which is durable and corrosion-resistant), 2-Way or 3-Way electric solenoid and globe or angle configurations. These valves have a quick reaction to opening and closing which is ideal for mist systems. The low inrush and holding currents allows longer wire runs from valve to controller. A new drip-tight diaphragm provides a tight seal. Flow control stem allows manual control and the simple inline installation requires minimal maintenance with maximum dependability.
Product Advantages
- Flow control stem allows manual control from full closure up to maximum capacity
- Suitable for dirty water applications with clog-free labyrinth inlet for command water.
- Quick reaction to opening and closing and a drip-tight seal for accurate irrigation.
- Available in multiple body configurations and control functions.
- Very low friction loss allows valve use with a wider range of flows.
- Durable, corrosion resistant materials for long life.
Proven Reliability with Reclaimed Water: Over a decade of field-proven, consistent performance under the harshest water conditions. Durable and corrosion-resistant materials.
2-Wire System Compatibility: Works with all major manufacturer 2-Wire control systems.
Applications
- Residential or commercial landscape irrigation applications
- For mild corrosive and mild acidity levels in the water
- For remote control, master valve, automated operations
- Reclaimed/reuse applications including municipally treated reclaimed water designated for irrigation
Specifications
- Recommended flow range:
- 3/4” – 0.01 to 26 GPM
- 1” – 0.01 to 44 GPM
- 1 1/2” – 0.25 to 110 GPM
- 2“ – 0.25 to 176 GPM
- Minimum operating pressure: 7 psi
- Maximum operating pressure: 150 psi
- Water temperature: up to 140° F
- Improved manual selector and encapsulated solenoid available on 3/4” and 1“ models only
- 24VAC solenoid standard +/- 10% voltage
- Solenoid inrush current: 0.220A
- Solenoid holding current: 0.095A
- Optional Solenoids: 24VDC, 12VDC, 12VDC-latching and 120VAC
- Integral stainless steel EasyClean® filter for 1.5” and 2” models only
- Adjustable pressure regulator option available: 1.5″ and 2″ model
- Normally Closed Option: 3/4″ – 2″
- Normally Open Option: 1 1/2″ – 2″
| Brand | Netafim |
|---|---|
| SKU | 71640-007355 |
| Weight (lb.) | 0.2500 |
| Prop 65 | false |
| Width (in.) | |
| Height (in.) | |
| Lead Time | 3-5 |
| Warranty | 1 Year |
| Length (in.) | |
| Hazardous Material | false |
| UPC | 3661734736107 |
| UL Listed | No |
| ETL Listed | No |
| Irrigation Part Type | |
| Hardware Diameter |
What are the main features of the Netafim Series 80 Globe Control Valve?
This valve offers lower friction loss for improved performance, quick reaction to opening and closing, and a drip-tight diaphragm for a tight seal. It's made from durable, corrosion-resistant materials and is compatible with 2-wire control systems.
Is the Netafim Series 80 Globe Control Valve suitable for use with reclaimed water?
Yes, this valve is proven reliable with reclaimed water and is designed for consistent performance even under harsh water conditions.
What applications is this valve best suited for?
The valve is ideal for residential or commercial landscape irrigation, remote control, master valve operations, and reclaimed/reuse applications, including municipally treated reclaimed water designated for irrigation.
