Octave® Ultrasonic Water Meters
Octave® Ultrasonic Water Meters have a ± 1.5% accuracy for nominal flow rates. The vacuum sealed and tamper proof register provides durability and long-term performance. A multi-line digital readout display provides immediate reporting and visual indicators for critical conditions. Lithium batteries provide a 10 year life expectancy. Octave also offers a 5 year pro-rated warranty – the industry’s longest.
Why Octave Water Meters?
- Double-beam ultrasonic sensors provide highly accurate flow data and reliable operation.
- No impeller or moving parts in the flow path provides for unrestricted, low pressure loss flows.
- Reduced maintenance of wear-prone parts commonly found in other meters.
- Flow ranges from <1 GPM to 5,500 GPM.
- Multi-line readout screen provides complete flow and volume information along with :
- Leak detection
- Flow direction
- Output mode
- Battery level
- Alarms and errors
- Active communication mode
- Vacuum sealed and tamper proof IP68 register provides durability and long-term performance.
- Lithium batteries provide a 10 year life expectancy.
Product Advantages
- Each meter has a unique, unalterable bar-coded serial number for identification.
- Standard registers are programmed to log and display both forward and reverse flow. Physically reversing the meter will not decrease the forward flow totalizer.
- Each meter ships with a certificate verifying flow accuracy with a ± 1.5% accuracy for nominal flow rates.
Specifications
- Sizes: 2″, 3″, 4″, 6″, 8″, 10″, and 12″
- Body: Epoxy-coated cast iron with flange inlet and outlet
- Maximum working pressure: 230 psi
- Fluid Temperature Range: 32° to 122° F (0.1° to 50° C)
- Connection: Flanges ANSI ISO for AWWA Connection Standard
- Power Source: 2 ‘D’ Size non-replaceable Lithium batteries
- Environmental Protection: IP-68, Ambient operation temperature for display: -13 to 131° F (-25° to 55° C)
- Output (optional): Programmable single/dual open collector pulse output or externally powered 4-20 mA loop
| Brand | Netafim |
|---|---|
| SKU | 00135-001474 |
| Weight (lb.) | 99.0000 |
| Prop 65 | false |
| Width (in.) | |
| Height (in.) | |
| Lead Time | This Product Ships in 10-14 Business Days |
| Length (in.) | |
| Hazardous Material | false |
| UPC | 3661734244992 |
| UL Listed | No |
| ETL Listed | No |
| Irrigation Part Type | Water / Soil Meters |
What does Netafim Octave Water Meter 8 Inch do in an irrigation system?
Netafim Octave Water Meter 8 Inch measures water flow and volume for irrigation and water systems. The meter uses double-beam ultrasonic sensors for accurate flow data and reliable operation.
What pulse output does Netafim Octave Water Meter 8 Inch use for monitoring?
Netafim Octave Water Meter 8 Inch is offered as a 1 and 10 gallons per pulse model.
What information does the digital readout on Netafim Octave Water Meter 8 Inch show?
Netafim Octave Water Meter 8 Inch has a multi-line digital readout that shows flow and volume information, leak detection, flow direction, output mode, battery level, alarms and errors, and active communication mode.
How accurate and durable is Netafim Octave Water Meter 8 Inch?
Netafim Octave Water Meter 8 Inch has ± 1.5% accuracy for nominal flow rates. The vacuum sealed, tamper proof IP68 register is built for durability and long-term performance, and the meter has no impeller or moving parts in the flow path for unrestricted, low pressure loss flow.
What connections does Netafim Octave Water Meter 8 Inch use?
Netafim Octave Water Meter 8 Inch uses flange inlet and outlet connections with ANSI ISO for AWWA Connection Standard.
What power source and warranty come with Netafim Octave Water Meter 8 Inch?
Netafim Octave Water Meter 8 Inch uses two D-size non-replaceable lithium batteries with a 10-year life expectancy. The meter also includes a 5-year pro-rated warranty.
