MRCOOL Product Documents
Easy Pro Brochure Install Instructions/Owners Manual Remote Control InstructionsInstall With Ease With The MRCOOL Easy Pro Do-It-Yourself Mini-Split
The MRCOOL Easy Pro Do-It-Yourself Mini Split packs huge cooling benefits in a easy to install package. With the ability to cool up to 1000 square feet, this is the perfect set up for open-concept homes, greenhouses, garages, and more! These systems include a 16 foot pre-charged line set so you're ready to go out of the box! These revolutionary linesets make installation safer, easier, and cheaper for the DIY'er at home. The Easy Pro also includes the new DIY PRO cables. These cables come encased to ensure protection from the environment, as well as curious animals and pesky lawnmowers! The MRCOOL Easy Pro DIY helps you save money with self installation, while increasing savings from standard AC units.
The MRCOOL Easy Pro DIY is based off of the industry leading MRCOOL DIY systems customers have come to know and love, but include a smaller line set and slightly lower SEER rating. This helps reduce the prices dramatically so MRCOOL can fit into anyones budget. Couplers are available to extend line sets to fit every need. These units also include a 1 year compressor and 2 year parts warranty so you can feel confident in feeling cool!
The MRCOOL Easy Pro includes almost all of the features of it's heavy weight counterparts. This includes features such as the "Follow Me" mode where your air conditioner unit focuses it's efforts where-ever you are as long as you have the remote with you. There's also the "Sleep Mode" which will maximize efficiency while you sleep soundly at night. With it's multitude of features and functions and it's groundbreaking price point, the Easy Pro DIY arrives as one of the most convenient, efficient options on the market.
MRCOOL Easy Pro Features & Benefits
Easy PRO Installation
Precharged 410 Quick Connect Lineset
16' pre-charged linesets allow you to install this innovative ductless system without special tools, equipment, or training. Couplers are available for extended lengths!
Smartphone App
Enhanced Control from Anywhere
Control your MRCOOL Easy PRO anywhere with your Apple or Android smart device and an internet connection.
NEW DIYPRO™ Cable
Safety & Durability
The included DIYPro™ Cable eliminates the need for electrical conduit providing higher mechanical protection and durability.
Follow Me® Function
Personalized Performance
Keep the remote close by, and MRCOOL Easy PRO will track the air temperature around you to ensure you receive maximum comfort.
Leakage Detection
Protecting Your Investment
When the MRCOOL Easy PRO detects low coolant an alarm will sound to alert you to the problem. This will prevent damage to the compressor while you maintain high air comfort.
Low Ambient Cooling
Cooling down to 5°F
This feature makes the MRCOOL Easy PRO the ideal system for server rooms, greenhouses, and any other application that requires cooling all year.
Sleep Mode
24-Hour Comfort
We made Sleep Mode easy to program to save money, and let you sleep a little easier.
Gold Fin Condenser
Corrosion Resistant
Live on the coast? Don’t worry, our condenser is built to resist long term corrosion.
Digital Assistant Ready
Google Assistant & Amazon Alexa
The new MRCOOL® Smart HVAC Controller® Module and App fully support Google Assistant & Amazon Alexa out of the box.
Best Warranty in the Business
1 Year Compressor & 2 Year Parts Warranty
Easy PRO include a hassle free 1-year compressor warranty, and a standard 2-year parts warranty for the original registered owner.
Specifications
| AC Unit Sizing | 9,000 BTU | 12,000 BTU | 18,000 BTU | 24,000 BTU |
|---|---|---|---|---|
| Cooling Capacity | 9,000 BTU | 12,000 BTU | 17,000 BTU | 24,000 BTU |
| SEER | 20 | 18 | 18.5 | 18 |
| Heating Capacity | 10,000 BTU | 12,000 BTU | 18,000 BTU | 25,000 BTU |
| HSPF4 | 10.3 | 11.1 | 9.7 | 10.3 |
| HSPF5 | 8.5 | 9.5 | 8 | 8.4 |
| Indoor Noise Level | 38.5/34/22.5 dB(A) | 42/35.5/27 dB(A) | 44.5/39/23.5 dB(A) | 45/40.0/27 dB(A) |
| Power Supply | 115V/60Hz/1Ph | 208-230V/60Hz/1Ph | 208-230//60Hz/1Ph | 208-230//60Hz/1Ph |
| Minimum Circuit Amperage | 20A | 20A | 15.5A | 21A |
| Maximum Fuse | 30A | 30A | 25A | 35A |
| Refrigerant (oz) | 26.49 | 32.1 | 45.86 | 62.79 |
| Piping Size (Liquid-side, Gas-side) | 1/4", 1/2" | 1/4", 1/2" | 1/4", 1/2" | 3/8", 5/8" |
| Indoor Net Dimensions | 28.70 x 7.87 x 11.50 in. | 31.57 x 7.87 x 11.61 in. | 38.23 x 8.98 x 12.64 in. | 42.60 x 9.21 x 13.27 in. |
| Outdoor Net Dimensions | 28.35 x 10.63 x 19.49 in. | 28.35 x 10.63 x 19.49 in. | 30.12 x 11.93 x 21.85 in. | 35.04 x 13.46 x 26.50 in. |
| Indoor Shipping Dimensions | 32.68 x 16.14 x 13.58 in. | 36.02 x 16.34 x 14.17 in. | 42.72 x 17.52 x 14.96 in. | 49.09 x 19.57 x 17.13 in. |
| Outdoor Shipping Dimensions | 33.15 x 14.06 x 22.83 in. | 33.15 x 14.06 x 22.83 in. | 35.04 x 14.96 x 24.61 in. | 40.55 x 17.24 x 28.74 in. |
| Inside Net/Gross Weight | 17.64/32.95 lbs. | 24.03/34.40 lbs. | 329.98/42.55 lbs. | 35.27/60.40 lbs. |
| Outside Net/Gross Weight | 54.45/71.1 lbs. | 55.11/71.1 lbs. | 63.49/79.43 lbs. | 97.66/115.1 lbs. |
Note: MRCOOL will not ship to Hawaii (HI). If you are in Hawaii, you will need to contact a freight forwarder.
| Brand | MRCOOL |
|---|---|
| SKU | MC-EPRO1 |
| Hazardous Material | false |
