Iluminar Product Documents
Iluminar iLogic FS Plus 1030 User Manual Iluminar iLogic FS Plus 1030 Spec SheetSmart and Scalable Full Spectrum Flowering LED
Covering large canopies with uniform and intense full spectrum light has never been this easy and efficient!
Supercharged Full Spectrum LED for the Most Demanding Cultivars
When it comes to sheer lighting power, the iLogic™FS Plus 1030W is the pinnacle of LED grow light performance. Engineered without compromise for the most light-hungry plant species, this cutting-edge fixture has the power and intensity to drive full genetic expression and unmatched crop quality.
Grow Beyond Your Expectations
Even seasoned indoor cultivators are surprised at the results the iLogic™FS Plus 1030W can deliver. Let’s not beat around the bush—this fixture is an absolute beast, capable of delivering consistent and reliable full spectrum light, enriched with bloom boosting reds, to drive your plants to their full potential.
Equipped with a high-end Sosen LED Driver and compatible with AC inputs ranging from 110V to 277V at 50/60Hz, all growers are able to benefit from its stability, reliability and efficiency.
New Generation High Intensity LED Lighting
Quality Components
Featuring a dynamic combination of Samsung LM281B+ Pro LEDs (3840 pcs) emitting at 4000K, along with Honglitronic SMD3535 660nm LEDs (256 pcs), the MegaGrow™ 1030W bathes your plants in a full spectrum of light tailored to their precise needs.
With a staggering Photosynthetic Photon Flux (PPF) output of 3140 µmol and an exceptional efficacy of 3.05 µmol/W, this fixture delivers unparalleled performance to maximize your yields.
Compatible and Controllable
Whatever the size of your growing operation, iLuminar has you covered when it comes to lighting control. Growers can choose to use our external PAD controller or our intuitive and easy to use smartphone app via Bluetooth connectivity to fully control light cycles and intensity.
Optional Upgrade: Iluminar Touch+ Grow Light Controller
The ILUMINAR Touch+ Controller will now allow you to control up to 60 lights per zone or room, with two channels you can control up to a total of 120 lights. This will take even your beginner garden to the commercial level, all of these features packed into the ILUMINAR Touch+ Controller.
The main difference between the Touch+ and the older Touch is greater dimming control. The old Touch controller could only control LEDs down to 50% dimming. The new Touch+ Controller can control dimming on LEDs all the way down to 20%
- LED + CMH + HPS All From One Controller
- Up to 120 Units, 60 fixtures per zone
- Control 2 Independent Rooms
- Auto Temperature Shut-Down
- Sunrise / Sunset Effects
- Battery Backup to Save Data
- Dual Temperature Zone input for High Heat Dimming
- Dual Temperature Probe Inputs
- Touch Screen Technology
- RJ9 to RJ14 cable included
Specifications for the Iluminar FS Plus 1030
Input Power | 120V to 277V |
---|---|
Power Consumption | 1030 ± 5% |
PPF | 3140 µmol/s |
PAR | 2.9 µmol/J |
Power Supplu | Sosen LED Drivers |
Power Factor | >0.9 |
THD | <10% |
Dimming | 0-100% dimming via RS485 |
Frequency | 50/60 Hz |
---|---|
BTU | 3500 |
LED Lifespan (90% of Life) | 50,000+ Hours |
Ambient Temp / Working | 0° - 35°C / 32° - 95°F |
Light Distribution | 120° |
Waterproof Rating | IP65 |
Color Temperature | 3600K |
Color Rendering Index | 85 |
Brand | Iluminar |
---|---|
SKU | IL-L1030FS-CONF |
Hazardous Material | false |
