Growlink relayLINK Spec SheetEffortless Automation for Your Grow Environment
Manage your grow environment with the 6-Channel relayLINK module. Control 24Vac signals for HVAC, humidifiers, dehumidifiers, and other mixed voltage equipment independently. This module integrates easily into your setup, allowing automated control of key systems to keep your environment running exactly as needed.
Growlink relayLINK Key Features:
- 6x 3.5A Dry Contacts: Operate up to eight separate devices independently, ideal for complex automation setups.
- LED Status Indicators: LED lights on the front panel provide real-time status for each relay, making monitoring and troubleshooting straightforward.
Growlink relayLINK Key Specs:
-
Input Power
- Voltage: 9-24VDC
- Current: 1.5A
-
Working Enviroment
- Temperature: 50-122°F (10-50°C)
- Humidity: 0-75%RH (Non-Condensing)
-
Functionality Inputs:
- (1x) RJ-45 Ports for Connection to Hub
-
Functionality Outputs:
- (6x) Form A (N.O.) Dry Contact Outputs. Each Output is rated for 1A Max. at 24v AC/DC
-
Package Contents:
- relayLINK
- Mounting Kit
- 10 ft. RJ-45 Cable
- Mini Screwdriver
