DABPRESS Personal Rosin Press Including 6-Ton Bottle Jack - 3x5" Heated Platens & Replaceable Bottle Jack Included - 500 Watts
Choose between the Rosin Press Only or the Rosin Press + Accessory Bundle
Upgraded Highlights
- Built-in PID temp controller.
- These upgraded machine legs provide additional stability and support, allowing for easier maneuverability and increased efficiency in completing tasks. To installing can serve as a Driptek, providing additional support when installed underneath.
- Provide the engineer mode instruction to protect the controller from being locked.
Features & Benefits
- Long Working Life Guaranteed - Durable frame made of H-shaped painted steel, paired with a replaceable 6-ton bottle jack, built-in spring inside of the frame; heating rods of power box have a 6,000 time of service life.
- Dual Controller and Thermocouple - Anodized working surface ensures the best flavor and easy cleaning; the design of independent heating rods and thermocouples guarantees an accurate temperature delivered & detected.
- Capable of 3.5-14g Materials - The 6-ton (12,000 lbs total force of pressure) hydraulic bottle jack delivers optimal pressure for solventless extraction; the filter of 2x3", 2x4", and 2.5x4.5" are recommended for use.
- Excellent Thermal Insulation Effect - Reduce heat transfer with a wood insulator guarantees quick heating-up and protects the bottle jack from overheating.
- Replaceable Bottle Jack & Controller - The bottle jack and PID temp controller allow replacement after not working to get a long service life.
How to Avoid the Filter Bags from Blowing Out?
- Remove excess stems from flowers.
- Use less material in your filter bag.
- Preheating your material first to get it melty before you begin to apply pressure.
- Apply the pressure more slowly.
Specifciations
- Temperature Range: 0-399F
- Power: 500 Watts
- Voltage: 110v
- Total Weight: 35.4lbs
- Package Dimension: 22" x 13.7" x 11.2"
- Frame Dimension: (H) 47cm x (W) 28.5cm x (D) 18cm
- PID Temp Controller Box Dimension: (H) 21.5cm x (W) 15cm x (D) 8.3cm
- Pressing Area: 3" x 5"
- Net Weight of Original Bottle Jack: 9.92lbs
- Minimum Height of Original Bottle Jack: 8.5"
- The diameter of the Original Bottle Jack: 2.8"
- Clearance between Upper and Bottom Platens: 35mm/1.37"
| Brand | Dabpress |
|---|---|
| SKU | DP-BJ6T35-US |
| Weight (lb.) | 35.4000 |
| Prop 65 | false |
| Length (in.) | |
| Width (in.) | |
| Height (in.) | |
| Lead Time | Ships in 3-7 business days |
| Hazardous Material | false |
| UPC | 600736913874 |
| ETL Listed | No |
| UL Listed | No |
| Rosin Press Type | Hydraulic |
| Plate Size | 3" x 5" |
| Plate Material Type | Anodized Aluminum |
| Temperature Range | 0-399 F |
| Temperature Control | PID Controller |
| Max. Pressure | 6 Ton |
| Pressure Control | Manual |
| Press Time Range | 0-999 |
| Adjustable Tilt Position | Yes |
| Needs Air Compressor | Not Required |
| Voltage | 110 Volts |
| Exact Watts | 500 Watts |
