Blue Diamond Product Documents
ETA Series SpecsheetThe ETA series range of air pumps ensures that there is plenty of water movement in wastewater applications; this boosts oxygen levels in the water, allowing aerobic bacteria to decompose. When used in medical applications, the ETA series provides a high flow at low pressure.
Features & Benefits
- Robust and compact construction - weatherproof
- Green drive technology offers energy efficient motors meaning low power consumption
- 30 to 500 litres per minute
- Ideal for large grow systems and koi ponds
- Supplied with a brass fitting and L shaped elbow
- Supplied with a rubber elbow for easy fitting.
| Model | Flow @ Pressure | Connector | Power | Dimensions (mm)(LxWxH) |
|---|---|---|---|---|
| ETA40 | 40.0 l/min @ (0.12 bar) | 18mm | 30W | 220 x 155 x 140mm |
| ETA60 | 60.0 l/min @ (0.12 bar) | 18mm | 55W | 253 x 165 x 183mm |
| ETA80 | 80.0 l/min @ (0.12 bar) | 18mm | 85W | 210 x 185 x 201mm |
| ETA100 | 100.0 l/min @ (0.12 bar) | 18mm | 105W | 238 x 196 x 207mm |
| ETA120 | 120.0 l/min @ (0.10 bar) | 18mm | 125W | 315 x 215 x 228mm |
| ETA150 | 150.0 l/min @ (0.20 bar) | 18mm | 125W | 346 x 200 x 222mm |
| ETA200 | 200.0 l/min @ (0.20 bar) | 18mm | 210W | 346 x 200 x 222mm |
| ETA250 | 250.0 l/min @ (0.20 bar) | 26mm | 221W | 348 x 231 x 219mm |
| ETA300 | 300.0 l/min @ (0.20 bar) | 26mm | 221W | 348 x 231 x 219mm |
| ETA400 | 400 l/min 0.20 bar | 26mm | 220W | 348 x 231 x 219mm |
| ETA500 | 500 l/min @ 0.20 bar | 26mm | 275W | 348 x 231 x 219mm |
NOTE: We recommend that enviro pumps are serviced at least every 18 months, service kits for each pump can be purchased at Hydrobuilder.com!
HYDROPONIC SYSTEMS
PONDS
| Brand | Blue Diamond |
|---|---|
| SKU | ET60A |
| Weight (lb.) | 10.0000 |
| Length (in.) | |
| Width (in.) | |
| Height (in.) | |
| Warranty | 2 Years |
| Hazardous Material | false |
| Lead Time | 2-3 |
| Prop 65 | false |
| ETL Listed | No |
| UL Listed | No |
| Parts & Accessories | Air Pumps |
| Pump Outlets | 1 |
| Voltage | 120 Volts |
| Exact Watts | 55 Watts |
What applications suit the Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm?
The Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm suits large grow systems, hydroponic systems, wastewater applications, medical applications, and koi ponds. The air pump circulates and aerates water to boost oxygen levels.
What airflow and pressure does the Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm provide?
The Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm provides 60 liters per minute at 0.12 bar.
What fittings and connection does the Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm include?
The Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm has an 18mm connector and one pump outlet. The air pump includes a brass fitting, an L-shaped elbow, and a rubber elbow.
Can the Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm be used indoors and outdoors?
The Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm has a weatherproof casing for indoor use and outdoor placement outside the grow room.
How often should the Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm receive service?
The Blue Diamond Enviro ETA-60 Linear Diaphragm Air Pump With Alarm should receive service at least every 18 months. Service kits for the air pump are available from HydroBuilder.
