Airbox 2 Stealth Edition 800 CFM (6" flanges)

SKU: HT4765
No reviews
Airbox Brand ProductMultiple Units? Click for Volume Pricing.

Availability: In stock

Lead time: This product ships in 5-7 business days


Price:
Sale Price$473.66
Product Documents1 file · spec sheet View

Air Box premium commercial-grade filters offer the most advanced system for improving indoor air quality. For residential, commercial and industrial environments.


Air Box circulates clean, healthy fresh air. Replaceable activated carbon filters destroy odors, capture organic and non-organic contaminants and scrub pathogens from the air. Air Box is a highly effective air filtering system that obliterates excess heat, destroys odors and circulates fresh air.

Activated carbon granules are an "absorbent" with well-developed pore structures allowing for a full range of absorbent retention. The high hardness number allows for minimal granular breakage and the kindling point of this activated carbon is usually high. This activated carbon is particularly well suited for removal of organic and non-organic contaminants. Air Box is the only modular, industrially designed carbon filter. Air Box is a sturdy metal enclosure designed to be easily hung in-line, inside or outside a residential, commercial or industrial environment. Replaceable high-flow carbon filters are made from exclusive 100% premium activated charcoal. Air-tight, it covers 100% of the filter surface area.


Airbox Stealth Edition Features:

  • Easy to install, easy to use, easy to maintain
  • Adaptable to any duct/filtering system
  • Replaceable high-flow carbon filters
  • 100% premium virgin coconut charcoal
  • 100% air tight, continuous worry-free operation
  • 100% of the filter surface area is used
  • For commercial or residential applications
  • Made in the USA

Note: Carbon filter should be changed often; please replace filters every 3 month (all of them) for better results.

Base Material Coconut Shell
Activation Method High Temp Steam
Carbon Tetrachloride Activity 60 CTS minimum
Particle Size 4x8
Hardness (ball abrasion) 97 minimum
Apparent Density (LBS/CU.FT) 31 average

Model Recommended Airflow Recommended Minimum Airflow Recommended CFM Max-CFM Pressure (W.G.) @ Recommended CFM
AirBox 1 166 @ 0.05 75 CFM 200 CFM 400 CFM 0.6 W.G.
AirBox 2 334 @ 0.05 400 CFM 400 CFM 800 CFM 0.6 W.G.
AirBox 3 600 @ 0.05 600 CFM 600 CFM 1200 CFM 0.6 W.G.
AirBox 4 800 @ 0.05 750 CFM 1000 CFM 2000 CFM 0.6 W.G.
AirBox 4+ 1500 @ 0.05 1000 CFM 1800 CFM 3500 CFM 1.2 W.G.

Inlet/Outlet Size Pre-Filter Number of Cartridges Unit Size Maximum Operating Temp Unit Weight
4" No 1 12.5" x 8.5" x 24" 176 F 18 lbs.
6" No 2 12.5" x 10" x 22.5" 176 F 24 lbs.
8" Yes 3 12.5" x 12" x 30" 176 F 45 lbs.
10” Yes 4 12.5”x 15” x 32” 176 F 59 lbs.
12” Yes 4+ 17.5”x 15” x 32" 176 F 120 lbs

Specifications

Filter TypeAir Box Filters

Product Details

BrandAirbox
SKUHT4765
Weight72.0 lb
Dimensions (L × W × H)39 × 22 × 19 in.
