Growers Choice GHS-730 Spec SheetAn Ideal Fixture For Supplemental Greenhouse Lighting
Introducing the new Growers Choice GHS-730, this sturdy commercial-grade light is designed and built for use in commercial horticultural facilities. The GHS-730 delivers one of the highest light outputs in the industry at 730 watts with excellent thermal management. Its sleek linear design eliminates unwanted shadows and makes it ideal for supplemental lighting in greenhouses. As an added benefit this fixture is also compatible with the Grower Choice CPS System - Central Power Solution
Features & Benefits of the GHS-730
- 2.6 umol/j efficacy
- 1800 umol/s PPF
- 4'x4' to 5'x5' coverage area
- GC-3k Full Spectrum
- Onboard dimming function 0-10v
- Compatible with Grower's Choice Master Lighting controller and new CPS
- Even light distribution
- Fanless Design
- IP65 Waterproof
- UL8800, UL 1598, DLC certification
- 5-Year warranty
Energy Output
The Growers Choice GHS-730 provides its users with an average 40% less HVAC costs and up to 40% energy savings! The GHS-730 not only maximizes light output to help penetrate the canopy and reach those hard to see leaves, but saves you money using less energy in the long run.
The Growers Choice GHS-730 LED grow light allows for even light distribution, and is precisely designed to deliver uniform levels of photosynthesis flux density, or PPFD.
Full Phase Spectrum
This fixture delivers the entire spectrum of light to your plants, giving them exactly what they need to grow big and beautiful. Grower's Choice famous GC-3K Full Phase Spectrum for will bring your plants to new heights with the best possible LED diodes available.
The highly specialized full spectrum fills the negligence of the main photoreceptors and pigments outside the 660nm and 450nm range, and it is suitable for reproduction to aging in indoor environments.
External Control with the Grower's Choice Master Lighting Controller
The GHS-730 is controllable with Grower’s Choice Master Controller and is compatible with all quality master controllers. Cultivators can set the fixture to turn off and on at desired times, program sunrise/sunset settings, program dimming options and set protective fail-safes to dim or turn off fixtures in the event of excessive room temperatures, such as in the event of an HVAC failure, potential saving gardens from heat damage.
This dual-channel controller allows daisy chaining up to 100 fixtures per zone. En-abling complete control of your growing environment with timed on/off switching, sunrise/sunset, and precise temperature readings with dual thermal probes and thermal-threshold auto dim-shutdown for additional protection.
Specifications for the GHS-730
| Model Number | GHS |
|---|---|
| Spectrum | GC-3K Full Phase |
| PPF | 1800 µmol/s |
| PAR | 2.6 µmol/J |
| Input power | 730 Watts |
| Mounting Height | Min 36" above canopy |
| Thermal Management | Passive |
| Max ambient temp | 104 °F/40°C |
|---|---|
| Dimming | 0-10V |
| Light Distribution | 120° |
| Power Factor | >90% |
| Lifetime | L90: > 54,000 hrs |
| Certifications | IP65, UL8800, UL1598, DLC |
| Warranty | 5 Year |
Voltage & Amperage
| Voltage | 120 Volt | 208 Volt | 240 Volt | 277 Volt |
|---|---|---|---|---|
| Amperage | 6.6 Amps | 4.6 Amps | 3.6 Amps | 2.9 Amps |
*PPF calculation compiled using Growers Choice in-house integrating sphere measurements and typical spectrodiometric data for each LED to determin the fixture performance. Actual photometric results may vary within the LED's manufacturers bin tolerance
*Wattage values are typical expected values. TSL Horti Tech maintains a tolerance of 10% range on flux and power consumption. Target light level can vary from projected levels depending on ambient temperature, room reflection values, and other conditions.
| Brand | Growers Choice |
|---|---|
| SKU | GHS-730 |
| Weight (lb.) | 30.0000 |
| Prop 65 | false |
| Length (in.) | |
| Width (in.) | |
| Height (in.) | |
| Warranty | 5 Year |
| Lead Time | This product ships in 2 weeks |
| Hazardous Material | false |
| Lighting Type | LED |
| LED Light Spectrum | Full Spectrum |
| LED Fixture Type | Bar/Strip |
| LED Features | Dimmable *with Controller |
| Est. Electricity Cost /mo | $31.53 |
| Exact Watts | 730 Watts |
| Suggested Hanging Height | > 36" Above Canopy |
| PAR Efficiency | 2.6 μmol/J |
| Total PPF Output | 1800 umol/s |
| Power Factor | > 90% |
| Voltage | 120 Volts, 208 Volts, 240 Volts, 277 Volts |
| Amps | 6.6 Amps @ 120 Volts, 4.6 Amps @ 208 Volts, 3.6 Amps @ 240 Volts, 2.9 amps @ 277 Volts |
| Power Cord(s) Included | Yes - 240 Volt Cord & 120 Volt Adapter |
| Power Cord Length | 8 Feet (1 foot power cord + 7 foot whip) |
| Coverage Area | Veg: 5' x 5'; Flower: 4' x 4' |
| Grow Light Certifications | IP65 Rated, DLC Listed, ETL Listed, UL Listed |
| ETL Listed | Yes |
| UL Listed | Yes |
